Vet Patient Monitor KM-15

Multi Parameter 15" Animal Monitor

Quality large 15" vet patient monitor. Includes full animal accessories, and specific veterinarian software.

Technical Specifications

  • Dimension: 365mm(W) × 330mm(H) × 160mm (D)
  • Weight: 5.3Kg
  • AC Power: AC 100-240 V, 50/60 Hz
  • Battery: Rechargeable, more than 60 minutes for continuous working
  • Display: 15”color TFT screen, multi displays selectable
  • Resolution: 1024×768
  • Language: English Spanish Chinese
  • Output: Standard RJ45 socket
  • Networking: Yes
  • Alarm: With limits setting, 3-level audible and visual alarm

ECG

  • Mode: 5-leads
  • Gain: x2.5, 5, 10, 20, 40mm/mv
  • Sweep Speed: 12.5mm/s, 25 mm/s, 50 mm/s,
  • Heart Rate Range: 15bpm ~ 350bpm
  • Resolution: 1bpm
  • Accuracy: ±1% or ±1bpm, whichever is larger
  • Scaling signal: 1mv±5%
  • CMRR: Diagnostic mode≥90dB
  • Monitoring mode≥105dB
  • Surgical mode≥105dB
  • Waveform Review: 120 minutes
  • Trend Time: 72 hours
  • Frequence Response: 0.05~120Hz
  • S-T segment detection: YES
  • Arrhythmia analysis: YES
  • Protection: Withstand 4000VAC/50Hz voltage in isolation
  • Against electrosurgical interference and defibrillation
  • Alarm: YES, 3-level audible and visual alarm, alarm events recallable

Respiration

  • Method: RA-LL Thoracic impedance
  • Measurement range: Adult: 0~120 BrPM; Neonate/Child: 0~150 BrPM
  • Resolution: 1/min
  • Accuracy: ±2/min or ±2%, whichever is larger
  • Alarm: YES, 3-level audible and visual alarm
  • Apnea alarm: 10s~40s
  • Gain: auto

NIBP

  • Method: Automatic oscillometric
  • Operation modes: Manual/Automatic/Continuous
  • Auto measure time: 1~280mins
  • Measurement unit: mmHg/kPa selectable
  • Measurement types: Systolic, Diastolic, Mean
  • Range of systolic pressure: Adult Mode: 40 - 270 mmHg
  • Pediatric Mode: 40 - 200 mmHg
  • Over-pressure protection: double safety protection
  • Alarm: Systolic, Diastolic, Mean; 3-level audible and visual alarm

SPo2

  • Measurement Range: 0~100%
  • Resolution: 1%
  • Accuracy: ±2% (70-100%, non-motion);
  • Alarm: 3-level audible and visual alarm
  • Pulse Measurement Range: 0~254bpm
  • Pulse Resolution: 1bpm
  • Pulse Alarm: 3-level audible and visual alarm

Temperature

  • Measurement Range: 0~50℃(32~122℉)
  • Resolution: 0.1℃
  • Accuracy: ±0.1℃ (excluding the sensor)
  • Channel: Single-channel or Dual-channel selectable. Provide T1; T2; ΔT
  • Alarm: 3-level audible and visual alarm

Standard Configuration
ECG+Respiration+NIBP+ SpO2+Pulse+Single Temperature+Lead acid battery

Record(Optional
Method: Built-in, thermal array
Traces Maximum: 3 tracks
Record Mode: Manual/Alarm/Timing
Paper Speed: 12.5mm/s, 25mm/s, 50mm/s

Options
Thermal Recorder
Stand and Mount
Li-ion Battery
