Model
|
KM-MCL-8071A
|
|
Pumping Mechanism
|
Curvilinear peristaltic
|
|
IV Set
|
Compatible with IV sets of any standard
|
|
Flow Rate
|
0.1-1200 ml/h (in 0.1 ml/h increments)
|
|
Purge, Bolus
|
100-1200mI/h (in 1 ml/h increments)
|
|
Accuracy
|
Purge when pump stops. bolus when pump starts
13%
|
|
VTBI
|
1-20000mI
|
|
Infusion Mode
|
ml/h, drop/min, time-based
|
|
KVO Rate
|
0.1-5ml/h
|
|
Alarms
|
Occlusion, air-in-line, door open, end program, low battery, end battery,
AC power off, motor malfunction, system malfunction, standby
|
|
Additional Features
|
Real-time infused volume, automatic power switching, mute key, purge,
bolus, system memory, key locker, compact portable, detachable, drug
library, change flow rate without stopping the pump.
|
|
Occlusion Sensitivity
|
High, medium, low
|
|
History log
|
30 days
|
|
Air-in-line Detection
|
Ultrasonic detector
|
|
Wireless Management
|
Optional
|
|
Vehicle Power (Ambulance)
|
12V
|
|
Power Supply. AC
|
AC100V-240V 50/60Hz
|
|
Battery
|
12V, rechargeable, 8 hours at 25mI/h
|
|
Working Temperature
|
10-30°C
|
|
Relative Humidity
|
30%-75%
|
|
Atmospheric Pressure
|
860-1060hPa
|
|
Size
|
150*125*60mm
|
|
Weight
|
1.7kgs
|
|
Safety Classification
|
Class II, type CF
|
